Waveshare Barcode Scanner Module, 1D/2D Codes Reader, 14810 – Durable Build, Easy to Use

Waveshare Barcode Scanner Module, 1D/2D Codes Reader, 14810 – Durable Build, Easy to Use.

Key Features:

• Overview
• 1. This is a small 1D/2D codes reader, by using the intelligent image recognition algorithm, it will decode the barcode or 2D code on paper or screen, fast...
• Through the onboard USB and UART interface, it can be directly plugged into a computer, or be easily integrated to kinds of devices due to its small form...
• Features
• 1. Easy to use, requires no knowledges of image recognition
• Decodes various common 1D/2D codes such as Barcode, QR code etc.
• Onboard micro USB and UART serial port, allows to connect with computers or embedded devices
• Configurable via scanning configuration code
• Onboard light source, works in the dark
• Specifications
• 1. Operating voltage: 5V
• Operating current: 135mA (scanning), 58mA (standby), 2mA (sleep)
• Operating temperature: 0°C~60°C
• Operating humidity: 5%~95% (Non-condensing)
• Communication interface: UART, USB
• Decodes 1D codes: Codebar, Code 11, Code 39/Code 93, UPC/EAN, Code 128/EAN128, Interleaved 2 of 5, Matrix 2 of 5, MSI Code, Industrial 2 of 5, GS1 Databar(RSS)
• Decodes 2D codes: QR code, Data Matrix, PDF417
• Light source: white
• Scan angels: roll 360°, skew ±65°, pitch ±60°
• Field of view: 28° (horizontal), 21.5° (vertical)
• Dimension: 53.3mm x 21.4mm
• Package contents:
• - Barcode Scanner Module x1
• - USB type A plug to micro B plug cable x1
• - PH2.0 4Pin x1

Package Info: Weight: 0.10kgs / 0.21lb, Size: 8cm * 4cm * 2cm / 3.15inch * 1.57inch * 0.79inch
