Waveshare 2.9 inch 296x128 Pixel E-Ink Three-color Display Module, 13339 – Durable Build, Easy to Use

Waveshare 2.9 inch 296x128 Pixel E-Ink Three-color Display Module, 13339 – Durable Build, Easy to Use.

Key Features:

• Overview
• This is an E-Ink display module, 2.9inch, 296x128 resolution, with embedded controller, communicating via SPI interface, supports red, black, and white...
• Due to the advantages like ultra low power consumption, wide viewing angle, clear display without electricity, it is an ideal choice for applications such...
• Features
• No backlight, keeps displaying last content for a long time even when power down
• Ultra low power consumption, basically power is only required for refreshing
• SPI interface, for connecting with controller boards like Raspberry Pi/Arduino/Nucleo, etc.
• Onboard voltage translator, compatible with 3.3V/5V MCUs
• Comes with development resources and manual (examples for Raspberry Pi/Jetson Nano/Arduino/STM32)
• Specifications
• Operating voltage: 3.3V/5V
• Interface: 3-wire SPI, 4-wire SPI
• Outline dimension: 89.5mm x 38mm
• Display size: 66.89mm x 29.05mm
• Dot pitch: 0.138 x 0.138
• Resolution: 296 x 128
• Display color: Red, black, white
• Grey level: 2
• Full refresh time: 15s
• Refresh power: 26.4mW(typ.)
• Standby power: <0.017mW
• Viewing angle: >170 degree
• Package Contents
• 2.9 inch e-Paper Module (B) x1
• PH2.0 20cm 8Pin x1

Package Info: Weight: 0.01kgs / 0.03lb, Size: 89cm * 38cm * 1cm / 35.04inch * 14.96inch * 0.39inch
