TB6560 3A 10V-35V Stepper Motor Driver Controller Board – TPU

TB6560 3A 10V-35V Stepper Motor Driver Controller Board – TPU.

Key Features:

• The working voltage is DC 10V-35V. It is recommended to use a switching power supply DC24V for power supply.
• Using 6N137 high-speed optical coupling to ensure high speed without losing step.
• Using Toshiba TB6560AHQ chip, there are built-in low-voltage shutdown, overheating shutdown and overcurrent protection circuits to ensure performance.
• The rated output (max) is: +/-3A, with a vertex value of 3.5A.
• It is suitable for two-phase/four-phase/four-wire/six-wire stepping motor with 42,57 stepping within 3A, but not suitable for stepping motor with more than 3A.
• Automatic half-flow function.
• Subdivision: Full step, half step, 1/8 step, 1/16 step, maximum 16 subdivision.
• Dimensions: Width 50 x length 75 x height 35 (MM)
• Weight: 83G
• This module does not have any protection circuit, so you must be very careful when using it, otherwise the chip is easy to burn out.
• Features in similar products:
• The current level can be adjusted step by step to meet your multiple application requirements.
• Automatic half flow is adjustable.
• Using 6N137 high-speed optical coupling to ensure high speed without losing step.
• The board printing instructions can be operated without manual.
• Adopt thick and densely toothed radiator for good heat dissipation.

Package Info: Weight: 0.09kgs / 0.20lb, Size: 25cm * 15cm * 3cm / 9.84inch * 5.91inch * 1.18inch
