LDTR-WG0211 DS3231 Clock Module 3.3V / 5V High Accuracy For Raspberry Pi – TPU

LDTR-WG0211 DS3231 Clock Module 3.3V / 5V High Accuracy For Raspberry Pi – TPU.

Key Features:

• This board can be used with Arduino /Raspberry Pi board
• Module itself can adapt 3.3V and 5V systems without level conversion.
• Features
• Within -40 degree C to +85 degree C temperature range, timing accuracy is maintained at +/- 5ppm (+/- 0.432 sec / day).
• Provide battery backup for continuous timing.
• Low-power.
• Device package and function compatible with the DS3231.
• Complete clock functions include seconds, minutes, hours, day, date, month and year timing, and provide valid to 2100.
• Two calendar alarm.
• 1Hz and 32.768kHz output.
• Reset button and button input.
• High-speed (400kHz) I2C serial bus.
• +2.3 V to +5.5 V supply voltage.
• +/-3 degree C accuracy digital temperature sensor.
• -40 degree C to +85 degree C operating temperature range.
• 16-pin SO (300mil) package
• Specification
• Brand: Landa tianrui
• Model: LDTR-WG0211
• Quantity: 1 piece
• Color: Black
• Material: PCB
• Chipset: DS3231
• Dimensions: 2.2 cm x 1.2 cm x 0.5 cm
• Weight: 5g
• Package List: 1 x DS3231 Clock Module

Package Info: Weight: 0.02kgs / 0.03lb, Size: 5cm * 3cm * 1cm / 1.97inch * 1.18inch * 0.39inch
