DSO138 Oscilloscope (Full Assembled) – Durable Build, Easy to Use

DSO138 Oscilloscope (Full Assembled) – Durable Build, Easy to Use.

Key Features:

• Features:
• This kit uses ARM Cortex-M3 processor (STM32F103C8), and includes a 2.4-inch color TFT display screen, can be used as ARM test development board.
• Can be secondary development on the basis of this kit, for example, it can be changed to Millivoltmeter, data loggers.
• Adjustable vertical displacement, and with instructions.
• With automatic, regular and one-shot modes, easy to capture the moment waveform.
• Available rising or falling edge trigger.
• Observable previous trigger waveform (negative delay).
• Can freeze at any time waveform display (HOLD function).
• Come 1Hz /3.3V square wave test signal source.
• With waveform parameter digital display, including frequency, period, pulse width, duty ratio, MAX./MIN./AVG./Peak-Peak/virtual values.
• Waveform storage function: will not lose the waveform after power off.
• Short-circuit and open-circuit detection: can help the user find out the soldering error.
• TFT controller recognition function.
• Note:
• This DIY kit is soldered.
• Specifications:
• Maximum Real-time Sampling Rate: 1Msps
• Accuracy: 12Bit
• Sampling Buffer Depth: 1024 bytes
• Analog Bandwidth: 0-200KHz
• Vertical Sensitivity: 10mV / Div - 5V / Div (1-2-5 progressive manner)
• Input Impedance: 1Mohm
• Maximum Input Voltage: 50Vpp (1: 1 probe), 400Vpp (10: 1 probe)
• Coupling Modes: DC / AC / GND
• The Horizontal Time Base Range: 10μs / Div - 50s / Div (1-2-5 progressive manner)
• Supply Voltage: DC 9V
• PCB Size: 117 * 76mm / 4.6 * 3in
• Screen Size: 52 * 40mm / 2 * 1.57in
• Package List:
• - 1 * DSO138 soldered Oscilloscope Kit
• - Soldering
• - 1 * Probe
• - 3 * User Manual(English)

Package Info: Weight: 0.15kgs / 0.33lb, Size: 20cm * 13cm * 3cm / 7.87inch * 5.12inch * 1.18inch

Shipping: Shipping charges and final delivery dates are shown at checkout.
