DC 12V 24V 48V Universal Electric Door RF Wireless Remote Control Relay Receiver Set – TPU

DC 12V 24V 48V Universal Electric Door RF Wireless Remote Control Relay Receiver Set – TPU.

Key Features:

• Shell material: ABS
• Product size: 68x48x18mm (excluding shell)
• Product net weight: 25g (excluding shell)
• Working frequency: 315MHz/433.92MHz
• Output mode: terminal block
• Control method: remote control with the same frequency
• Working mode: inching, self-locking, interlocking
• Working voltage: DC12-36V
• Standby current: 9.8mA
• No-load maximum operating current: 96mA
• Receive sensitivity: -105dBm
• Working temperature: -20-70 degrees Celsius
• Notice:
• The supply voltage cannot exceed the working voltage.
• In an environment with strong wireless interference, the receiving distance may be reduced.
• Keep out of reach of children.
• It is forbidden to use it in a humid environment, otherwise it may cause damage to the controller.

Package Info: Weight: 0.14kgs / 0.30lb, Size: 10cm * 6cm * 3cm / 3.94inch * 2.36inch * 1.18inch
