BU-353N5 USB GPS Receiver SiRF Star IV Magnetic

BU-353N5 USB Interface G Mouse GPS Receiver SiRF Star IV Module, BU-353N5 – Waterproof, Magnetic, TPU

BU-353N5

£44.99

BU-353N5 USB Interface G Mouse GPS Receiver SiRF Star IV Module, BU-353N5 – Waterproof, Magnetic, TPU

£44.99

BU-353N5 USB Interface G Mouse GPS Receiver SiRF Star IV Module, BU-353N5 – Waterproof, Magnetic, TPU.

Key Features:

About The Product
The BU-353N5 is a USB GPS receiver that features a highly sensitive, low power consumption chipset in a ultra compact form factor. The BU-353N5 is powered...
Features
SiRF Star IV high performance GPS Chipset
Highly sensitive (Tracking Sensitivity: -163 dBm)
Extremely fast TTFF (Time To First Fix) at low signal level
Support NMEA 0183 data protocol
Built-in SuperCap to reserve system data for rapid satellite acquisition
Built-in patch antenna and magnetic pad
Super-cohesive magnetic for mounting on the car
Waterproof and non-slip on the bottom
LED indocator for GPS
Specifications
Chipset: SiRF Star IV
Frequency: L1 1575.42MHz
C / A code: 1.023 MHz chip rate
Number of Channels: 48 channels tracking
Sensitivity: -163dBm
Accuracy
Location: 10 meters, 2D RMS
5 meters, 2D RMS, WAAS enable
Rate: 0.1 m/s
Time: 1 microsecond synchronized satellite
Other Characters
Coordinate information:
- Default: WGS-84
Acquisition Time:
- Readmission: Average 0.1 seconds
- Hot Start: Average 1 seconds
- Warm start: 38 sec average
- Cold and warm start: 42 sec average
Related restrictions:
- Height: 18,000 m (60,000 ft) maximum
- Rate: 515 m / sec (10,000 knots) maximum
- Gravity: Less than 4G
Power:
- Main power input: 4.5V ~ 6.5V DC input
- Power consumption: 80mA
Agreement:
- Operational level: TTL level
- Output Voltage: 0V ~ 2.85V
- Transfer rate: 4,800 bps
- Output format: NMEA 0183 GGA, GSA, GSV, RMC, VTG, GLL
Physical Characteristics:
- Size: 53mm diameter, 19.2mm height
- Cable length: 1.5 m
- Operating temperature: -40 degree C to +85 degree C
